Trident CLO Closed-Loop Automatic Defluxing / Cleaning System is available in four throughput configurations.

Trident CLO - One process chamber
Trident CLO DUO - Two process chambers (shown above)
Trident CLO TRIO - Three process chambers
Trident CLO QUAD - Four process chambers

Trident CLO High-Yield Series
Closed-Loop Fully Automatic Cleaning Systems
Features:

  • Removes Water Soluble Fluxes
  • Closed-Loop (Zero Discharge) Cleaning Cycle
  • Available in multiple throughput configurations
  • Automatic Cleaning and Dying Cycles
  • Built-In Programmable Cleanliness Verification Testing
  • Built-In Rinse Closed-Loop Water Recycling System
  • Unlimited Program Recipes (for each process chamber)
  • Graphic User Touchscreen Interface (one for each process chamber)
  • Advanced Statistical Process Control (SPC) Data-Logging with Barcode Scanner (one for each process chamber)
  • High-Power Forced Hot-Air Convection + Radiant Drying System (for each process chamber)
  • Built-In Programmable Maintenance Reminders (for each process chamber)
  • Upper Board Rack Ready (each process chamber)
  • LED Status Light Tower (for each process chamber)

Trident CLO provides fully automatic cleaning, cleanliness verification, and dry functions. The Trident CLO removes water soluble fluxes and does so without sending a single from of fluid to the drain. Need to remove Rosin and No-Clean flux residues? Click -HERE-
Each Trident CLO process chamber is equipped with an asymmetrical fan-jet spray system. Twin stainless steel counter rotating spray bars featuring twenty stainless steel fan-jet nozzles project precision-diffused deionized water onto a shadow-mitigating oscillating board rack. This spray system was implemented to deliver controlled fluid energy underneath fine-pitch components. The Each Trident CLO process chamber is pre-plumbed to accept an upper board rack assembly for even higher throughput.

Features:
Dimensions:
DUO:  86”W x 48”D x 71”H
TRIO: 129”W x 48”D x 71”H
QUAD: 171”W x 48”D x 71”H
Electrical Requirements: 208-240 3Ø 40 amps (per chamber)
Control System: Windows 7 PC User Interface Touchscreen
Advanced SPC Data Collection
Assembly Barcode Scanning Capability (barcode scanner included)
Built-In Cleanliness Verification Technology: Standard
Construction: Welded Steel Tube Frame with Steel Panels
Finish: Baked Powder-Coat Hammer-Tone Finish
Plumbing Materials: Stainless Steel
Fluid Delivery Technology: 20 Asymmetrically Placed 15° Stainless Steel Nozzles
Number of Process Chambers: 1 Standard (2-4 Optional)
