Trident ECO Low Discharge Automatic Defluxing / Cleaning System is available in four throughput configurations.
Trident ECO - One process chamber
Trident ECO DUO - Two process chambers (shown above)
Trident ECO TRIO - Three process chambers
Trident ECO QUAD - Four process chambers
Trident High-Yield ECO Series
Low Discharge Fully Automatic Cleaning Systems
Features:
- Removes Any Flux From Any Alloy
- Closed-Loop (Zero Discharge) Wash Cycle
- Filtered Discharge Rinse Cycle
- Available in multiple throughput configurations
- Automatic Wash, Rinse, and Dry Cycles
- Unlimited Program Recipes (for each process chamber)
- Graphic User Touchscreen Interface (one for each process chamber)
- Optional Real-Time Chemical Concentration Monitoring
- Drying System (for each process chamber)
The Trident ECO High-Yield Cleaning System provides fully automatic wash, rinse, and dry functions in a higher throughput / flexibility environment compared to single-chambered models. The Trident ECO High-Yield Cleaning Systemremoves any flux from any alloy.
Equipped with an asymmetrical fan-jet spray system in each process chamber, Trident ECO's twin stainless steel counter rotating spray bars feature twenty stainless steel fan-jet nozzles project precision-diffused wash solution and rinse water onto a shadow-mitigating oscillating board rack. This spray system was implemented to deliver controlled fluid energy underneath fine-pitch components.
Features:
Dimensions:
DUO: 86”W x 48”D x 71”H
TRIO: 129”W x 48”D x 71”H
QUAD: 171”W x 48”D x 71”H
Electrical Requirements: 208-240 3Ø 40 amps (per chamber)
Control System: Windows 7 PC User Interface Touchscreen (for each chamber)
Construction: Welded Steel Tube Frame with Steel Panels
Finish: Baked Powder-Coat Hammer-Tone Finish
Plumbing Materials: Stainless Steel
Fluid Delivery Technology: 20 Asymmetrically Placed 15° Stainless Steel Nozzles
Number of Process Chambers: 1-4
