Low Discharge Automatic Defluxing-Cleaning
and Cleanliness Verification System


Trident LDO

Fully Automatic Cleaning and Cleaniness Verification System

  • Removes Any Flux From Any Alloy
  • Closed-Loop (Zero Discharge) Wash Cycle
  • Low Discharge Rinse Cycle
  • Automatic Wash, Rinse, and Dry Cycles
  • Built-In Programmable Cleanliness Verification Testing
  • Unlimited Program Recipes
  • Graphic User Touchscreen Interface
  • Automatic Chemical Dosing and Mixing System
  • Optional Real-Time Chemical Concentration Monitoring
  • Advanced Statistical Process Control (SPC) Data-Logging with Available Barcode Scanner (learn more HERE)
  • High-Power Forced Hot-Air Convection + Radiant Drying System
  • Built-In Programmable Maintenance Reminders

Trident LDO provides fully automatic wash, rinse, cleanliness verification, and dry functions at the push of a single button. Equipped with an asymmetrical fan-jet spray system, Trident LDO's twin stainless steel counter rotating spray bars feature twenty stainless steel fan-jet nozzles project precision-diffused wash solution and rinse water onto a shadow-mitigating oscillating board rack. This spray system was implemented to deliver controlled fluid energy underneath fine-pitch components.

Trident LDO includes a closed loop (zero discharge) wash solution section and an low-discharge rinse section.

Features:
Dimensions: 44.75"W x 44.25D x 70”H
Electrical Requirements: 208-240 3Ø 40 amps
Chemical Dosing and Mixing: Automatic 5% - 20% Concentrations
Control System: Windows 7 PC User Interface Touchscreen
Advanced SPC Data Collection
Assembly Barcode Scanning Capability (barcode scanner optional)
Built-In Cleanliness Verification Technology: Standard
Construction: Welded Steel Tube Frame with Steel Panels
Finish: Baked Powder-Coat Hammer-Tone Finish
Plumbing Materials: Stainless Steel
Fluid Delivery Technology: 20 Asymmetrically Placed 15° Stainless Steel Nozzles
Number of Process Chambers: 1 Standard (2-4 Optional)
