Trident CLO Dual-Chamber Higher Throughput Model
Click to enlarge

Trident’s SPC Capabilities

Features

  • Removes Water Soluble (OA) Flux

  • Cleans Using DI Water Only (No Chemicals)

  • Built-In DI Water Regeneration System

  • Fully Closed-Loop Operation

  • Automatic Cleaning and Drying Cycles

  • Built-In Programmable Resistivity Monitoring System

  • Unlimited Program Recipes

  • Graphic User Touchscreen Interface

  • Windows 10 Networkable PC Control System

  • A-SPC Advanced Statistical Process Control Data Collection System with Multi-Querry Search and Optional Barcode Scanner

  • Password Protected Recipe Editor

  • Password Protected Administration Screen

  • Large Graphic User Touchscreen Interface

  • High-Power Forced Hot-Air Convection + Radiant Drying System

  • Built-In Programmable Maintenance Reminders

  • Available in Single-Chamber and Dual-Chamber Configurations


Zero Discharge

Inspired by our pursuit of drain-free technology, Trident CLO is an environmentally responsible fully automated cleaning system. Trident CLO is equipped with a built-in DI water generation system and is fully closed-loop alleviating the requirement for a drain.

Trident CLO operates in a water-only configuration and is designed to remove water soluble fluxes and other polar (water soluble) residues.

Features:

  • Dimensions: 42 ¼”Dx 56”W x 70”H

  • Electrical Requirements:
    208-240 VAC 3Ø 40 amps
    400 VAC 3Ø 30 amps

  • Control System: Windows 10 Professional Operating System with PC Touchscreen User Interface

  • Advanced SPC Data Collection with SQL Database (Learn More)

  • Advanced Multi-Query SPC Search Capabilities with Built-In Report Generator

  • Available Assembly Barcode Scanning

  • Built-In Programmable Cleanliness Verification Technology Allows Preset Desired Cleanliness Levels

  • Zero Discharge Operation

  • Built-In Water Filtration, Re-Deionization, and Re-Use System

  • Construction:
    Welded Steel Tube Frame with Steel Panels

  • Finish:
    Baked Powder-Coat Hammer-Tone Finish

  • Plumbing Materials:
    Stainless Steel

  • Fluid Delivery Technology:
    20 Asymmetrically Placed 15° Stainless Steel Nozzles
    Oscillating Board Rack for Shadow Mitigation

  • Number of Process Chambers: 1 Standard (2 Optional)
